Creating Forign JMS Server configuration through WLST script

WebLogic JMS enables you to reference foreign (that is, external) JMS providers within a local WebLogic JNDI tree. Using the Foreign JMS Server node, you can quickly map a foreign JMS provider so that its connection factories and destinations appear in the WebLogic JNDI tree as a local JMS objects. A Foreign JMS Server configuration can also be used to reference remote instances of WebLogic Server in another cluster or domain in the local WebLogic JNDI tree

The below WLST script help us to create a Foreign JNDI server in a local server for a JMS resources running in a remote server(in different domain).

The JMS clients can use the local JNDI configured in the local server to send the messages to the remote JMS server.

ConfigureForeignJMSServer.py

connect('weblogic','welcome1', 't3://localhost:9001')
edit()
startEdit()

cd('/')
cmo.createJMSSystemResource('BAMForeginJMSResource')

cd('/SystemResources/BAMForeginJMSResource')
set('Targets',jarray.array([ObjectName('com.bea:Name=AdminServer,Type=Server')], ObjectName))

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource')
cmo.createForeignServer('BAMForeignJMSServer')

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource/ForeignServers/BAMForeignJMSServer')
cmo.setDefaultTargetingEnabled(true)

cmo.setJNDIPropertiesCredential('welcome1')

cmo.setConnectionURL('t3://localhost:8000')
cmo.createJNDIProperty('java.naming.security.principal')

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource/ForeignServers/BAMForeignJMSServer/JNDIProperties/java.naming.security.principal')
cmo.setValue('weblogic')

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource/ForeignServers/BAMForeignJMSServer')

cmo.createForeignConnectionFactory('ForeignJMSConnectionFactory')

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource/ForeignServers/BAMForeignJMSServer/ForeignConnectionFactories/ForeignJMSConnectionFactory')
cmo.setLocalJNDIName('jms/BAMMonitoringConnectionfactory')
cmo.setRemoteJNDIName('jms/BAMMonitoringConnectionfactory')

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource/ForeignServers/BAMForeignJMSServer')
cmo.createForeignDestination('ForeignJMSDestination')

cd('/JMSSystemResources/BAMForeginJMSResource/JMSResource/BAMForeginJMSResource/ForeignServers/BAMForeignJMSServer/ForeignDestinations/ForeignJMSDestination')
cmo.setLocalJNDIName('jms/BAMMonitoringQueue')
cmo.setRemoteJNDIName('jms/BAMMonitoringQueue')

activate()


The same script can be modified to create a Foreign JNDI Server for other JMS providers.

Login to the server, cd to the folder where the script is available and execute the script as shown below.

%MIDDLEWARE_HOME%\wlserver_10.3\common\bin\wlst.cmd ConfigureForeignJMSServer.py

Creating JMS Adapter connection factory through WLST script

The below WLST script will help us to create the JMS adapter connection factories. Before Executing the script change the details accordingly.

configureJMSAdapterConnection.py

TargetServerName='AdminServer'

soaHome='oracle/Middleware/Oracle_SOA1'

appPathJms=soaHome+'/soa/connectors/JmsAdapter.rar'
appNameJms='JmsAdapter'
moduleOverrideNameJms=appNameJms+'.rar'
JMSJNDIName = 'eis/wls/BAMQueueConnection'
JMSConnectionfactory='jms/BAMMonitoringConnectionfactory'
#Sever Details

moduleDescriptorName='META-INF/weblogic-ra.xml'
planPathJms=soaHome+'/soa/connectors/Plan_JMS.xml'

def createJMSConnectionFactory():

        edit()
        startEdit()
        startApplication(appNameJms)
        myPlanJms=loadApplication(appPathJms, planPathJms)
        makeDeploymentPlanVariable(myPlanJms,'ConnectionInstance_eis/Jms_JNDIName_13102979357209', JMSJNDIName , '/weblogic-connector/outbound-resource-adapter/connection-definition-group/[connection-factory-interface="oracle.tip.adapter.jms.IJmsConnectionFactory"]/connection-instance/[jndi-name="'+JMSJNDIName+'"]/jndi-name',moduleOverrideNameJms)
        makeDeploymentPlanVariable(myPlanJms, 'ConfigProperty_eis/JMS_JNDIName_ConnectionFactory_Name_13102979357210', JMSConnectionfactory,'/weblogic-connector/outbound-resource-adapter/connection-definition-group/[connection-factory-interface="oracle.tip.adapter.jms.IJmsConnectionFactory"]/connection-instance/[jndi-name="'+JMSJNDIName+'"]/connection-properties/properties/property/[name="ConnectionFactoryLocation"]/value',moduleOverrideNameJms)

        myPlanJms.save();
        save();
        cd('/AppDeployments/JmsAdapter/Targets');
        updateApplication(appNameJms, planPathJms);
        activate(block='true');


def makeDeploymentPlanVariable(wlstPlan, name, value, xpath,overrideName, origin='planbased'):
    wlstPlan.destroyVariable(name)
    wlstPlan.destroyVariableAssignment(name, overrideName, moduleDescriptorName)
    variableAssignment = wlstPlan.createVariableAssignment(name, overrideName, moduleDescriptorName)
    variableAssignment.setXpath(xpath)
    variableAssignment.setOrigin(origin)
    wlstPlan.createVariable(name, value)
    print 'moduleDescriptorName=',moduleDescriptorName


def main():
       adminURL='t3://localhost:9001'
       adminUserName='weblogic'
       adminPassword='welcome1'
       connect(adminUserName, adminPassword, adminURL)
       createJMSConnectionFactory()
       disconnect()
main()

Login to the server, cd to the folder where the script is available and execute the script as shown below.

%MIDDLEWARE_HOME%\wlserver_10.3\common\bin\wlst.cmd configureJMSAdapterConnection.py

Setting up the JMS resources through WLST script

The below WLST script help us to set up the JMS resources.

JMSConpiguration.py

connect('weblogic','weblogic', 't3://localhost:8000')

edit()
startEdit()

print 'Creating File Store'
cd('/')
cmo.createFileStore('BAMMonitoringJMSFileStore')
cd('/FileStores/BAMMonitoringJMSFileStore')
cmo.setDirectory('BAMMonitoringJMSFileStore')
set('Targets',jarray.array([ObjectName('com.bea:Name=AdminServer,Type=Server')], ObjectName))


print 'Creating JMS Server'
cd('/')
print 'Creating JMS Server.'
cmo.createJMSServer('BAMMonitoringServer')
cd('/JMSServers/BAMMonitoringServer')
cmo.setPersistentStore(getMBean('/FileStores/BAMMonitoringJMSFileStore'))
cmo.setTemporaryTemplateResource(None)
cmo.setTemporaryTemplateName(None)
cmo.addTarget(getMBean('/Servers/AdminServer'))

print 'Creating JMS Module'
cd('/')
cmo.createJMSSystemResource('BAMJMSSystemResource')
cd('/JMSSystemResources/BAMJMSSystemResource')
cmo.addTarget(getMBean('/Servers/AdminServer'))
cmo.createSubDeployment('BAMSubdeDloyment')

print 'Creating Connection Factory'
cd('/')
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource')
cmo.createConnectionFactory('BAMMonitoringConnectionfactory')
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource/ConnectionFactories/BAMMonitoringConnectionfactory')
cmo.setJNDIName('jms/BAMMonitoringConnectionfactory')
#set('SubDeploymentName','BAMSubdeDloyment')
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource/ConnectionFactories/BAMMonitoringConnectionfactory/SecurityParams/BAMMonitoringConnectionfactory')
cmo.setAttachJMSXUserId(false)
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource/ConnectionFactories/BAMMonitoringConnectionfactory/ClientParams/BAMMonitoringConnectionfactory')
cmo.setClientIdPolicy('Restricted')
cmo.setSubscriptionSharingPolicy('Exclusive')
cmo.setMessagesMaximum(10)
#cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource/ConnectionFactories/BAMMonitoringConnectionfactory/TransactionParams/BAMMonitoringConnectionfactory')
#cmo.setXAConnectionFactoryEnabled(true)
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource/ConnectionFactories/BAMMonitoringConnectionfactory')
cmo.setDefaultTargetingEnabled(true)

print 'Creating Queue'
cd('/')
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource')
cmo.createQueue('BAMMonitoringQueue')
cd('/JMSSystemResources/BAMJMSSystemResource/JMSResource/BAMJMSSystemResource/Queues/BAMMonitoringQueue')
set('JNDIName','jms/BAMMonitoringQueue')
set('SubDeploymentName','BAMSubdeDloyment')
cd('/JMSSystemResources/BAMJMSSystemResource/SubDeployments/BAMSubdeDloyment')
cmo.addTarget(getMBean('/JMSServers/BAMMonitoringServer'))

print 'JMS Resources are Successfully Created'
activate()

Executing the script:

Set the environment by executing the below script

$WL_Home/wlserver_10.3/server/bin/setWLSEnv.sh

Execute JMSConpiguration.py

Wlst.sh JMSConpiguration.py

Migrating the BAM objects across environments with the ANT script – Oracle BAM 11g

This post explains how to use the ANT script to migrate the BAM objects across the environments.The script can be run remotely from the client machine or from the server machine.

• Create a folder BAMConfig and create two sub folders BAMObjects and config inside the BAMConfig folder
• Copy the BAMICommandConfig.xml from $ORACLE_HOME/bam/config folder of the server to the config folder created in the above step.
• Add the default user name and the password to the BAMICommandConfig.xml file

           <ICommand_Default_User_Name>weblogic</ICommand_Default_User_Name>
           <ICommand_Default_Password>hiyEbs0vwXPQrKh8yE7z3f7JVNhmLLEe+cR3bansiPc=</ICommand_Default_Password>

         Also verify the ADCServerPort - the BAM Server http listening port and   ADCServerName -  BAM Server host name properties.

Content of the configuration file:

<?xml version="1.0" encoding="UTF-8"?><BAMICommand>
<ADCServerPort>9001</ADCServerPort>
<ADCServerName>BAM Server hostname</ADCServerName>
<ICommand_Default_User_Name>weblogic</ICommand_Default_User_Name>
<ICommand_Default_Password>hiyEbs0vwXPQrKh8yE7z3f7JVNhmLLEe+cR3bansiPc=</ICommand_Default_Password>
<Communication_Protocol>t3</Communication_Protocol>
<SensorFactory>oracle.bam.common.statistics.noop.SensorFactoryImpl</SensorFactory>
<GenericSatelliteChannelName>invm:topic/oracle.bam.messaging.systemobjectnotification</GenericSatelliteChannelName>
</BAMICommand>

Default password should be encrypted else you will be receiving “ICommandEngine.MissingCredentials” error.

To encrypt the password configure the BAMICommandConfig.xml file in the $ORACLE_HOME/bam/config folder with the plain text password and run any standard icommand from the server (e.g $ORACLE_HOME/bam/bin/icommand -cmd export -type dataobject -name SampleDO -file C:\temp\SampleDO.xml) that will encrypt the password.

• Create Export_BAM_Objects.xml file with the BAM export commands and place the same in BAMConfig folder created in the above step, the contents of the file look like below

<OracleBAMCommands>
   <!--import dataobjects-->
    <Export name="/Albin/BAMWebservice" type="dataobject" file="$BAM_PROJ_HOME$/BAMWebservice.xml"/>
    <Export name="/SampleDO" type="dataobject" file="$BAM_PROJ_HOME$/SampleDO.xml"/>
</OracleBAMCommands>
Configure the required export commands (exporting different type of objects) into this file.

• Create Import_BAM_Objects.xml file with the BAM import commands and place the same in BAMConfig folder created in the above step, the contents of the file look like below

<OracleBAMCommands>
   <!--import dataobjects-->
   <Import file="$BAM_PROJ_HOME$/BAMWebservice.xml"/>
</OracleBAMCommands>
Configure the required import commands into this file.

• Create the BAMBuild.xml file with the following contents and place the same in the BAMConfig folder created in the above step.

<project name="BAMMigrationProject" basedir="." default="config">
   <!--import the property file-->
   <property environment="env"/>
   <property name="src.dir" value="."/>
   <property name="proj.home" value="${env.BAM_PROJ_HOME}"/>
   <property name="oracle.home" value="${env.ORACLE_HOME}"/>
   <property name="oracle.common.home" value="${env.ORACLE_COMMON_HOME}"/>
   <property name="bam.core.lib.dir" value="${env.ORACLE_HOME}/bam/modules/oracle.bam_11.1.1"/>
   <property name="bam.tp.lib.dir" value="${env.ORACLE_HOME}/bam/modules/oracle.bam.thirdparty_11.1.1"/>
   <property name="dms.lib.dir" value="${env.ORACLE_COMMON_HOME}/modules/oracle.dms_11.1.1"/>
   <!--BAM Classpath required by icommand application-->
   <path id="bamClasspath">
      <fileset file="${bam.core.lib.dir}/oracle-bam-icommand.jar"/>
      <fileset file="${bam.core.lib.dir}/oracle-bam-common.jar"/>
      <fileset file="${bam.core.lib.dir}/oracle-bam-adc-ejb.jar"/>
      <fileset file="${dms.lib.dir}/dms.jar"/>
      <fileset file="${bam.tp.lib.dir}/jgroups-core.jar"/>
      <fileset file="${bam.tp.lib.dir}/xstream-1.3.1.jar"/>
      <fileset file="${bam.tp.lib.dir}/commons-codec-1.3.jar"/>
      <fileset file="${oracle.home}/../wlserver_10.3/server/lib/weblogic.jar"/>
      <fileset file="${oracle.common.home}/modules/org.jaxen_1.1.1.jar"/>
   </path>
   <!--export BAM DOs through icommand-->
   <target name="export" description="Export BAM dataobjects and reports" depends="config">
    <delete dir="${basedir}/BAMObjects" includeemptydirs="true" includes="*/**"></delete>
      <java classname="oracle.bam.icommand.Application" fork="true" dir="${src.dir}" classpathref="bamClasspath">
         <sysproperty key="oracle.bam.debug" value="true"/>
         <arg value="-CmdFile"/>
         <arg value="${basedir}/Export_BAM_Objects.xml"/>
      </java>
   </target>
   <!--import BAM DOs through icommand-->
   <target name="import" description="Import BAM dataobjects and reports" depends="config">
      <java classname="oracle.bam.icommand.Application" fork="true" dir="${src.dir}" classpathref="bamClasspath">
         <sysproperty key="oracle.bam.debug" value="true"/>
         <arg value="-CmdFile"/>
         <arg value="${basedir}/Import_BAM_Objects.xml"/>
      </java>
   </target>
   <!--Modify bam icommand files-->
   <target name="config">
       <!--replace $project.home$ with the actual project directory inside the command file-->
      <replace file="Export_BAM_Objects.xml" token="$BAM_PROJ_HOME$" value="${basedir}/BAMObjects"/>
      <replace file="Import_BAM_Objects.xml" token="$BAM_PROJ_HOME$" value="${basedir}/BAMObjects"/>
   </target>
</project>

• To run the scripts from the server copy the BAMConfig folder with all the contents to the server.Set the environment variables ORACLE_HOME and ORACLE_COMMON_HOME(e.gORACLE_HOME=/oracle/Middleware/Oracle_SOA1;export ORACLE_HOME;ORACLE_COMMON_HOME=oracle/Middleware/oracle_common;export ORACLE_COMMON_HOME) and also set the PATH to ANT(e.g export PATH=$PATH:$ORACLE_HOME/../modules/org.apache.ant_1.7.1/bin)

         Execute the ant scripts

          ant –f BAMBuild.xml export

        The objects will be exported based on the commands in the Export_BAM_Objects.xml as an xml file   to the BAMObjects folder

         ant –f BAMBuild.xml import

           The xml file contents will be imported to BAM based on the commands in the Import_BAM_Objects.xml

• To run the script from the client machine the JDeveloper with the same version as the BAM server should be installed.Set the ORACLE_HOME (e.g C:\EnvSetup\MiddlewareBlog\jdeveloper) and ORACLE_COMMON_HOME(e.g C:\EnvSetup\MiddlewareBlog\oracle_common) environment variables and also set the PATH to ANT

        Copy the commons-codec-1.3.jar file from the server location   ${env.ORACLE_HOME}/bam/modules/oracle.bam.thirdparty_11.1.1 to the <JDEV_HOME>\ jdeveloper\bam\modules\oracle.bam.thirdparty_11.1.1

Run the ant script

Different integration approaches to send the event data to Oracle BAM 11g

Oracle BAM provides a framework for Creating dashboards that display real-time data based on the events.
There are multiple approaches to send the event data to BAM.This document explains some of the approaches to send the data to BAM.

Different approaches to send event data to BAM

Building a Simple ADF page using BAM Data Control

The BAM reports can be built through BAM Active Studio or through BAM data control in ADF page.

In this blog I will be explaining about the steps required to build a simple ADF page using BAM data control.

Creating the BAM Connection:

• Open the JDeveloper
• Create new BAM Connection

• Enter the BAM Server details as shown below.

• Click on Finish and Test the connection
• Create the data object in BAM through Architect view (I am using the existing data object Employee)

• Create a new Generic Application

• Enter the Application name as BAMReport and click on Next
• Enter the Project name as BAMReport and Select ADF Faces from the list

•  Click on Finish
• Right click the project and create new JSF page

• Enter the file name as BAMReport and click on OK

Creating the BAM Data Control:

• Locate the BAM data object based on which the report needs to be created from the BAM server connection panel.

•  Right click the data object (Employee) and click on Create Data Control.

• Enter the configuration details as shown below (Change the details according to your requirement)

• Click on Finish, the data control created can be looked from the Data Control panel.

• Drag and drop the data Control (Query) to the BAMReport.jspx page and Select Table, ADF Read Only Table.

• Remove the id column from the report

• Click on OK

• Save the project.
• Create the EAR deployment profile for the application and don’t deploy the application to the server (Refer http://www.albinsblog.com/2012/12/problem-while-deploying-adf-application.html#.UNQQVqycaS0 )
• Follow the steps Enable the MDS for the Application from http://www.albinsblog.com/2012/12/runtime-exception-in-oracle-adf.html#.UNQP6aycaS0 to configure the MDS for the project and deploy the application to the server.
• Follow the steps Configure the BAM connection from http://www.albinsblog.com/2012/12/runtime-exception-in-oracle-adf.html#.UNQP6aycaS0 to configure the runtime BAM connection details for the application.
• Test the application by accessing the following URL http://localhost:9001/BAMreport/faces/BAMReport.jspx

• Login to the BAM architect and add the new record to the Employee data object, the same will be displayed in the page automatically without refreshing the page as shown below.
